Infrared Temperature Sensor PSC-CS-LT15-TC-K

Price 1.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

Infrared Temperature Sensor PSC-CS-LT15-TC-K Specification

Pressure Range
Atmospheric

Resolution
0.1C

Connectivity Type
4-20 mA Output / Thermocouple Type K

Protection
IP65

Application Media
Suitable for solids, liquids and gases

Temperature Range
-20C to +350C

Humidity %
< 95% RH, non-condensing

Sensor Type
Non-contact Infrared

Current Range
4-20 mA Output

Equipment Type
Infrared Temperature Sensor

Diameter
15 mm (sensor head)

Measurement Range
-20C to +350C

Material
Stainless Steel

Power Supply
24 V DC

Power Consumption
< 50 mA

Accuracy
1% of reading or 1C

Display Type
No built-in display

Range
0C to 85C

Infrared Temperature Sensor PSC-CS-LT15-TC-K Trade Information

Minimum Order Quantity
1 Number

Supply Ability
2 Per Day

Delivery Time
2 Days

Main Domestic Market
All India

About Infrared Temperature Sensor PSC-CS-LT15-TC-K

Model-PSC-CS-LT15-TC-K

Outputs: 0-10 V or 0-5 Vfree scalable

Temperature range: -40C to 1030C

Responsetime:25ms

OpticalResolution15:1

Usable up to 80C ambient temperaturewithout cooling

Accuracy- +/-1.5%

Application

Used forCommon Application for example-Non-metal,rubber,

plastic, wood, food product etc.Notusedforshinysurface ,Glass

High Accuracy Measurement for Industrial Needs

The PSC-CS-LT15-TC-K delivers 1% or 1C accuracy and 0.1C resolution, making it ideal for industrial temperature monitoring tasks. Its fast 150 ms response time enables real-time process control. With a wide measurement range and robust design, it operates dependably even in demanding settings, providing consistently reliable data.

Versatile Applications and Easy Integration

Suitable for measuring the temperature of solids, liquids, and gases, this sensor is a strong fit for manufacturing, energy, and process industries. The threaded or fixed mounting and support for both 4-20 mA and Thermocouple Type K outputs facilitate seamless integration with various control systems. Factory calibration ensures quick setup right out of the box.

FAQ's of Infrared Temperature Sensor PSC-CS-LT15-TC-K:

Q: How do I install the PSC-CS-LT15-TC-K infrared temperature sensor?

A: The sensor can be mounted using its threaded or fixed brackets for stable positioning. Ensure the sensor is placed with an unobstructed line of sight to the target surface to obtain accurate measurements. The standard 1 m cable can be extended if needed for installation flexibility.

Q: What benefits does the non-contact infrared measurement provide?

A: Non-contact infrared technology allows temperature readings of moving or hard-to-reach objects without physical contact, reducing wear and contamination risks. This method ensures fast, accurate, and safe measurements under various industrial conditions.

Q: When should I use this sensor's 4-20 mA or Thermocouple Type K outputs?

A: Choose the 4-20 mA output when integrating with PLCs or process controllers that require analog current signals. Use the Type K thermocouple output if your monitoring equipment or data loggers are compatible with standard thermocouple inputs.

Q: Where can this infrared sensor be used?

A: This sensor is versatile and can be used in multiple environments, including manufacturing lines, energy plants, and laboratory settings, for monitoring the temperature of solids, liquids, or gases. Its IP65-rated stainless steel construction makes it suitable for industrial atmospheres.

Q: What is the process for calibrating the PSC-CS-LT15-TC-K sensor?

A: The sensor comes factory calibrated, eliminating the need for initial user calibration. Periodic recalibration is generally not required but can be arranged by qualified service providers if needed for quality assurance.

Q: How accurate are the temperature readings from this sensor?

A: The PSC-CS-LT15-TC-K offers an accuracy of 1% of the reading or 1C, with a resolution of 0.1C across a measurement range of -20C to +350C, making it suitable for precise industrial applications.
